Aderendhülsen nach DIN 46228/1, E-Cu verzinnt

Eigenschaften

*** PROGRAMM FÜR DEN INSTALLATEUR ***

Aderendhülsen nach DIN 46228 Teil 1 aus Kupfer

- Für fein- und feinstdrähtige Leiter z.B. VDE 0295 Klasse 5 und 6
- Gratfrei, mit Aufweitung für spleissfreie Kabeleinführung
- Verpresste Aderendhülsen zur einfachen Montage an Kabelklemmen
- Gesamtquerschnitt: 0,25 - 240 mm²
- Nach DIN 46228 Teil 1 und ähnliche

Oberfläche:
- Galvanisch verzinnt

Technische Daten

Bauform
Standard
Isoliert
Nein
Halogenfrei
Ja
Werkstoff
Kupfer
Oberflächenschutz
verzinnt
Für kurzschlussfeste Leitungen
Nein
Mit Kennzeichnungsfahne
Nein
Bandware
Nein
Menge Art.Nr. Bezeichnung E-Nummer Lager EAN Nennquerschnitt Hülsenlänge d1 d2 s VE Einheit
VZ 1211/5-0,25/GH Aderendhülse 0.25 mm², 5 mm 156400417 7611971004275 0.25 mm² 5 mm 0.75 mm 1.7 mm 0.15 mm 1'000 Stk
VZ 1211/7-0,25/GH Aderendhülse 0.25 mm², 7 mm 156400427 7611971004282 0.25 mm² 7 mm 0.75 mm 1.7 mm 0.15 mm 1'000 Stk
VZ 1211/10-0,25/GH Aderendhülse 0.25 mm², 10 mm 156400407 7611971004268 0.25 mm² 10 mm 0.75 mm 1.7 mm 0.15 mm 1'000 Stk
VZ 1311/7-0,34/GH Aderendhülse 0.34 mm², 7 mm 156400447 7611971004329 0.34 mm² 7 mm 0.85 mm 1.8 mm 0.15 mm 1'000 Stk
VZ 1412/6-0,5/GH Aderendhülse 0.5 mm², 6 mm 156400007 7611971004398 0.5 mm² 6 mm 1 mm 2.1 mm 0.15 mm 100 Stk
VZ 1412/8-0,5/GH Aderendhülse 0.5 mm², 8 mm 156400017 7611971004411 0.5 mm² 8 mm 1 mm 2.1 mm 0.15 mm 100 Stk
VZ 1412/10-0,5/GH Aderendhülse 0.5 mm², 10 mm 156400027 7611971004336 0.5 mm² 10 mm 1 mm 2.1 mm 0.15 mm 100 Stk
VZ 1412/12-0,5/GH Aderendhülse 0.5 mm², 12 mm 156400037 7611971003940 0.5 mm² 12 mm 1 mm 2.1 mm 0.15 mm 100 Stk
VZ 1614/6-0,75/GH Aderendhülse 0.75 mm², 6 mm 156400107 7611971004510 0.75 mm² 6 mm 1.2 mm 2.3 mm 0.15 mm 100 Stk
VZ 1614/8-0,75/GH Aderendhülse 0.75 mm², 8 mm 156400117 7611971004534 0.75 mm² 8 mm 1.2 mm 2.3 mm 0.15 mm 100 Stk
VZ 1614/10-0,75/GH Aderendhülse 0.75 mm², 10 mm 156400127 7611971004435 0.75 mm² 10 mm 1.2 mm 2.3 mm 0.15 mm 100 Stk
VZ 1614/12-0,75/GH Aderendhülse 0.75 mm², 12 mm 156400137 7611971004459 0.75 mm² 12 mm 1.2 mm 2.3 mm 0.15 mm 100 Stk
VZ 1614/15-0,75/GH Aderendhülse 0.75 mm², 15 mm 156400147 7611971004473 0.75 mm² 15 mm 1.2 mm 2.3 mm 0.15 mm 100 Stk
VZ 1816/6-1/GH Aderendhülse 1 mm², 6 mm 156400207 7611971004640 1 mm² 6 mm 1.4 mm 2.5 mm 0.15 mm 100 Stk
VZ 1816/8-1/GH Aderendhülse 1 mm², 8 mm 156400217 7611971004664 1 mm² 8 mm 1.4 mm 2.5 mm 0.15 mm 100 Stk
VZ 1816/10-1/GH Aderendhülse 1 mm², 10 mm 156400227 7611971004558 1 mm² 10 mm 1.4 mm 2.5 mm 0.15 mm 100 Stk
VZ 1816/12-1/GH Aderendhülse 1 mm², 12 mm 156400237 7611971004572 1 mm² 12 mm 1.4 mm 2.5 mm 0.15 mm 100 Stk
VZ 1816/15-1/GH Aderendhülse 1 mm², 15 mm 156400247 7611971004602 1 mm² 15 mm 1.4 mm 2.5 mm 0.15 mm 100 Stk
VZ 1816/20-1/GH Aderendhülse 1 mm², 20 mm 156400257 7611971004626 1 mm² 20 mm 1.4 mm 2.5 mm 0.15 mm 100 Stk
VZ 2118/6-1,5/GH Aderendhülse 1.5 mm², 6 mm 156400307 7611971004787 1.5 mm² 6 mm 1.7 mm 2.8 mm 0.15 mm 100 Stk
VZ 2118/8-1,5/GH Aderendhülse 1.5 mm², 8 mm 156400317 7611971004817 1.5 mm² 8 mm 1.7 mm 2.8 mm 0.15 mm 100 Stk
VZ 2118/10-1,5/GH Aderendhülse 1.5 mm², 10 mm 156400327 7611971004688 1.5 mm² 10 mm 1.7 mm 2.8 mm 0.15 mm 100 Stk
VZ 2118/12-1,5/GH Aderendhülse 1.5 mm², 12 mm 156400337 7611971004701 1.5 mm² 12 mm 1.7 mm 2.8 mm 0.15 mm 100 Stk
VZ 2118/15-1,5/GH Aderendhülse 1.5 mm², 15 mm 156400347 7611971004732 1.5 mm² 15 mm 1.7 mm 2.8 mm 0.15 mm 100 Stk
VZ 2118/20-1,5/GH Aderendhülse 1.5 mm², 20 mm 156400357 7611971004763 1.5 mm² 20 mm 1.7 mm 2.8 mm 0.15 mm 100 Stk
VZ 2623/6-2,5/GH Aderendhülse 2.5 mm², 6 mm 156400507 7611971004923 2.5 mm² 6 mm 2.2 mm 3.4 mm 0.15 mm 100 Stk
VZ 2623/8-2,5/GH Aderendhülse 2.5 mm², 8 mm 156400517 7611971004954 2.5 mm² 8 mm 2.2 mm 3.4 mm 0.15 mm 100 Stk
VZ 2623/10-2,5/GH Aderendhülse 2.5 mm², 10 mm 156400527 7611971004831 2.5 mm² 10 mm 2.2 mm 3.4 mm 0.15 mm 100 Stk
VZ 2623/12-2,5/GH Aderendhülse 2.5 mm², 12 mm 156400537 7611971004855 2.5 mm² 12 mm 2.2 mm 3.4 mm 0.15 mm 100 Stk
VZ 2623/15-2,5/GH Aderendhülse 2.5 mm², 15 mm 156400547 7611971004879 2.5 mm² 15 mm 2.2 mm 3.4 mm 0.15 mm 100 Stk
VZ 2623/20-2,5/GH Aderendhülse 2.5 mm², 20 mm 156400557 7611971004909 2.5 mm² 20 mm 2.2 mm 3.4 mm 0.15 mm 100 Stk
VZ 3128/8-4/GH Aderendhülse 4 mm², 8 mm 156400717 7611971005067 4 mm² 8 mm 2.8 mm 4 mm 0.2 mm 100 Stk
VZ 3128/10-4/GH Aderendhülse 4 mm², 10 mm 156400727 7611971004978 4 mm² 10 mm 2.8 mm 4 mm 0.2 mm 100 Stk
VZ 3128/12-4/GH Aderendhülse 4 mm², 12 mm 156400737 7611971004992 4 mm² 12 mm 2.8 mm 4 mm 0.2 mm 100 Stk
VZ 3128/15-4/GH Aderendhülse 4 mm², 15 mm 156400747 7611971005012 4 mm² 15 mm 2.8 mm 4 mm 0.2 mm 100 Stk
VZ 3128/20-4/GH Aderendhülse 4 mm², 20 mm 156400757 7611971005043 4 mm² 20 mm 2.8 mm 4 mm 0.2 mm 100 Stk
VZ 4743/10-6/GH Aderendhülse 6 mm², 10 mm 156400827 7611971005098 6 mm² 10 mm 3.5 mm 4.7 mm 0.2 mm 100 Stk
VZ 4743/12-6/GH Aderendhülse 6 mm², 12 mm 156400837 7611971005111 6 mm² 12 mm 3.5 mm 4.7 mm 0.2 mm 100 Stk
VZ 4743/15-6/GH Aderendhülse 6 mm², 15 mm 156400847 7611971005135 6 mm² 15 mm 3.5 mm 4.7 mm 0.2 mm 100 Stk
VZ 4743/20-6/GH Aderendhülse 6 mm², 20 mm 156400857 7611971005166 6 mm² 20 mm 3.5 mm 4.7 mm 0.2 mm 100 Stk
VZ 4743/25-6/GH Aderendhülse 6 mm², 25 mm 156400867 7611971005180 6 mm² 25 mm 3.5 mm 4.7 mm 0.2 mm 100 Stk
VZ 5854/12-10/GH Aderendhülse 10 mm², 12 mm 156401137 7611971005203 10 mm² 12 mm 4.5 mm 5.8 mm 0.2 mm 100 Stk
VZ 5854/15-10/GH Aderendhülse 10 mm², 15 mm 156401147 7611971005227 10 mm² 15 mm 4.5 mm 5.8 mm 0.2 mm 100 Stk
VZ 5854/20-10/GH Aderendhülse 10 mm², 20 mm 156401157 7611971005258 10 mm² 20 mm 4.5 mm 5.8 mm 0.2 mm 100 Stk
VZ 5854/25-10/GH Aderendhülse 10 mm², 25 mm 156401167 7611971005272 10 mm² 25 mm 4.5 mm 5.8 mm 0.2 mm 100 Stk
VZ 7368/12-16/GH Aderendhülse 16 mm², 12 mm 156401237 7611971005296 16 mm² 12 mm 5.8 mm 7.5 mm 0.2 mm 100 Stk
VZ 7368/15-16/GH Aderendhülse 16 mm², 15 mm 156401247 7611971005319 16 mm² 15 mm 5.8 mm 7.5 mm 0.2 mm 100 Stk
VZ 7368/20-16/GH Aderendhülse 16 mm², 20 mm 156401257 7611971005340 16 mm² 20 mm 5.8 mm 7.5 mm 0.2 mm 100 Stk
VZ 7368/25-16/GH Aderendhülse 16 mm², 25 mm 156401267 7611971005364 16 mm² 25 mm 5.8 mm 7.5 mm 0.2 mm 100 Stk
VZ 7368/30-16/GH Aderendhülse 16 mm², 30 mm 156401277 7611971005388 16 mm² 30 mm 5.8 mm 7.5 mm 0.2 mm 100 Stk
VZ 8882/12-25/GH Aderendhülse 25 mm², 12 mm 156401307 7611971005401 25 mm² 12 mm 7.3 mm 9.5 mm 0.2 mm 50 Stk
VZ 8882/15-25/GH Aderendhülse 25 mm², 15 mm 156401317 7611971005425 25 mm² 15 mm 7.3 mm 9.5 mm 0.2 mm 50 Stk
VZ 8882/18-25/GH Aderendhülse 25 mm², 18 mm 156401327 7611971005449 25 mm² 18 mm 7.3 mm 9.5 mm 0.2 mm 50 Stk
VZ 8882/20-25/GH Aderendhülse 25 mm², 20 mm 156401337 7611971005463 25 mm² 20 mm 7.3 mm 9.5 mm 0.2 mm 50 Stk
VZ 8882/25-25/GH Aderendhülse 25 mm², 25 mm 156401357 7611971005487 25 mm² 25 mm 7.3 mm 9.5 mm 0.2 mm 50 Stk
VZ 8882/28-25/GH Aderendhülse 25 mm², 28 mm 156401377 7611971005500 25 mm² 28 mm 7.3 mm 9.5 mm 0.2 mm 50 Stk
VZ 9091/12-35/GH Aderendhülse 35 mm², 12 mm 156401407 7611971005524 35 mm² 12 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9091/15-35/GH Aderendhülse 35 mm², 15 mm 156401417 7611971005548 35 mm² 15 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9091/18-35/GH Aderendhülse 35 mm², 18 mm 156401427 7611971005562 35 mm² 18 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9091/20-35/GH Aderendhülse 35 mm², 20 mm 156401437 7611971005586 35 mm² 20 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9091/22-35/GH Aderendhülse 35 mm², 22 mm 156401447 7611971005616 35 mm² 22 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9091/25-35/GH Aderendhülse 35 mm², 25 mm 156401457 7611971005630 35 mm² 26 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9091/30-35/GH Aderendhülse 35 mm², 30 mm 156401477 7611971005678 35 mm² 30 mm 8.3 mm 11 mm 0.2 mm 20 Stk
VZ 9550/18-50/GH Aderendhülse 50 mm², 18 mm 156401527 7611971005708 50 mm² 18 mm 10.5 mm 13 mm 0.3 mm 20 Stk
VZ 9550/20-50/GH Aderendhülse 50 mm², 20 mm 156401537 7611971005722 50 mm² 20 mm 10.5 mm 13 mm 0.3 mm 20 Stk
VZ 9550/22-50/GH Aderendhülse 50 mm², 22 mm 156401547 7611971005746 50 mm² 22 mm 10.5 mm 13 mm 0.3 mm 20 Stk
VZ 9550/25-50/GH Aderendhülse 50 mm², 25 mm 156401557 7611971005760 50 mm² 25 mm 10.5 mm 13 mm 0.3 mm 20 Stk
VZ 9550/30-50/GH Aderendhülse 50 mm², 30 mm 156401577 7611971005791 50 mm² 30 mm 10.5 mm 13 mm 0.3 mm 20 Stk
VZ 9670/22-70/GH Aderendhülse 70 mm², 22 mm 156401747 7611971005821 70 mm² 22 mm 12.7 mm 15 mm 0.4 mm 25 Stk
VZ 9670/25-70/GH Aderendhülse 70 mm², 25 mm 156401757 7611971005845 70 mm² 25 mm 12.7 mm 15 mm 0.4 mm 20 Stk
VZ 9670/30-70/GH Aderendhülse 70 mm², 30 mm 156401777 7611971005876 70 mm² 30 mm 12.7 mm 15 mm 0.4 mm 25 Stk
VZ 9795/25-95/GH Aderendhülse 95 mm², 25 mm 156402057 7611971005906 95 mm² 25 mm 14.7 mm 17 mm 0.4 mm 10 Stk
VZ 9795/30-95/GH Aderendhülse 95 mm², 30 mm 156402077 7611971005937 95 mm² 30 mm 14.7 mm 17 mm 0.4 mm 10 Stk
VZ 9795/34-95/GH Aderendhülse 95 mm², 34 mm 156402087 7611971005951 95 mm² 34 mm 14.7 mm 17 mm 0.4 mm 10 Stk
VZ 9812/30-120/GH Aderendhülse 120 mm², 30 mm 156402177 7611971005975 120 mm² 30 mm 16.7 mm 19 mm 0.5 mm 10 Stk
VZ 9812/34-120/GH Aderendhülse 120 mm², 34 mm 156402187 7611971005982 120 mm² 34 mm 16.7 mm 19 mm 0.5 mm 10 Stk
VZ 9812/38-120/GH Aderendhülse 120 mm², 38 mm 156402197 7611971005999 120 mm² 38 mm 16.7 mm 19 mm 0.5 mm 10 Stk
VZ 9915/34-150/GH Aderendhülse 150 mm², 34 mm 156402387 7611971006002 150 mm² 34 mm 18.7 mm 21 mm 0.5 mm 10 Stk
VZ 9915/38-150/GH Aderendhülse 150 mm², 38 mm 156402397 7611971006019 150 mm² 38 mm 18.7 mm 21 mm 0.5 mm 10 Stk
VZ 9985/32-185/GH Aderendhülse 185 mm², 32 mm 156432329 7611971006026 185 mm² 32 mm 20.2 mm 23.5 mm 0.5 mm 10 Stk
VZ 9985/40-185/GH Aderendhülse 185 mm², 40 mm 156432339 7611971006033 185 mm² 40 mm 20.2 mm 23.5 mm 0.5 mm 10 Stk
VZ 9991/40-240/GH Aderendhülse 240 mm², 40 mm 156432409 7611971006057 240 mm² 40 mm 23 mm 24 mm 0.5 mm 10 Stk
Änderungen vorbehalten
